FEATURES • BENEFITS
Carbon block filter finely polishes water for
high quality beverage and food applications
Sanitary cartridge replacement is simple,
quick and clean; internal filter parts are
never exposed to handling or contamination
Reduces chlorine taste & odor and other
offensive contaminants that can adversely
affect the taste of water and beverages
Reduces extra fine dirt and particles as
small as five (5) microns in size*
Does not remove fluoride
NSF® Certified under NSF Standards 42
*As tested by Pentair
INSTALLATION TIPS
Never use saddle valve for connection.
Use 3/8" water line.
Install vertically with cartridge
hanging down.
Allow 21
⁄2" (6.35 cm) clearance below the
cartridge for easy cartridge replacement.
Flush 4CB5 Cartridge by running water
through filter for five (5) minutes at
full flow.
OPERATION TIPS
Change cartridges on a regular six (6)
month preventative maintenance program.
Change cartridges when capacity is
reached or when pressure falls below
10 psi (0.7 bar).
Service flow rate must not exceed 1.67 gpm
(6.3 Lpm).
Always flush the filter cartridge at time of
installation and cartridge change.
SIZING
Service Flow Rate: Maximum 1.67 gpm
(6.3 Lpm)
Rated Capacity: 6,000 gallons (22,710 L)
SPECIFICATIONS
Service Flow Rate
Maximum 1.67 gpm (6.3 Lpm)
Rated Capacity
6,000 gallons (22,710 L)
Pressure Requirements
10 - 125 psi (0.7 - 8.6 bar), non-shock
Temperature
35 - 100°F (2 - 38°C)
Overall Dimensions
14.5" L x 3.25" D. (36.9 cm x 8.2 cm)
